X-ray inspection machine Xmark 7
Xray inspection machine Xmark 7
- Stage 360 °rotation, axis 7 linkage
- System magnified 1500 times
- Software setting voltage and current
- Powerful CNC detection,Automatic detecting BGA soldering
- Powerful software analysis functions,can be upgraded to CT
- Visual image navigation
Description
X-ray Inspection Machine Xmark 7
X-ray inspection machine X-mark 7 is an X-ray inspection system designed for high-precision quality control and safety inspection across manufacturing smt line PCB assembly applications. Combining superior image quality with automated detection capabilities, this system delivers unmatched inspection accuracy and throughput.
|
Model |
|
Xmark 7 |
|
X-RAY launching tube |
Tube Type |
Sealed type X-ray tube |
|
Tube voltage |
40KV-130KV |
|
|
Tube current |
10-300uA |
|
|
Focal size |
5-15 um |
|
|
Detector |
Image speed |
20 fps |
|
Resolution |
1536*1536 |
|
|
Tilt angle |
Loading platform 360° rotation，Detector Tilting 60°，Easily to detect the BGA soldering |
|
|
Cabinet Specifications |
Stage size |
500mm*500mm |
|
Dimension |
L170*W177*H177cm |
|
|
Net Weight |
1900kg |
|
|
Input voltage |
AC 110-220V （+10%）（international general power supply） |
|
|
X-ray leakage amount |
≤1 u Sv/h |
|
|
operating system |
Windows 7 |
|
|
Total power |
2.5Kw |
|
Key Features
PCB X-ray inspection image recognition technology
- Dual-energy X-ray detection system with 0.5mm sensitivity
- High-resolution 17″ LCD monitor displaying 16-bit grayscale images
- Real-time image enhancement and contrast optimization
- 160kV power source enabling penetration of dense materials
Intelligent Detection
- AI-powered contamination detection algorithm for PCB X-ray inspection
- Automatic recognition of product shape and density variations
- Multi-zone density analysis for precise inspection
- Customizable detection parameters for different products
Safety and Compliance
- Radiation protection meeting FDA and CE standards
- Lead-free curtains with safety interlocks
- Emergency stop buttons on both sides
- Radiation leakage < 0.5 μSv/h at any point 10cm from cabinet surface
Production Efficiency
- Belt speed adjustable from 0.2 to 0.8 meters per second
- Maximum product height: 300mm
- Maximum product width: 400mm
- Throughput up to 200 items per minute
User-Friendly Operation
- Intuitive touchscreen interface
- One-touch product changeover
- Automatic system calibration
- Remote diagnostic capabilities
- Data logging and reporting functions
Quality Assurance
- Automatic reject system for contaminated products
- HACCP compliance
- Full production data tracking
- Export capabilities for quality reports
Applications
- Food and beverage production
- Pharmaceutical manufacturing
- Electronics assembly PCB x-ray inspection machine
- Consumer goods packaging
- Industrial components inspection
Technical Specifications
- Power Supply: 220V/50Hz
- Power Consumption: 1.5kW
- Operating Temperature: 0-40°C
- Humidity Range: 20-90% non-condensing
- Machine Dimensions: 2000mm (L) x 1000mm (W) x 1500mm (H)
- Conveyor Height: 800mm ± 50mm
- Weight: 850kg
Support and Service
- 24/7 technical support
- Comprehensive warranty coverage
- Preventive maintenance programs
- Operator training included
- Remote monitoring capabilities
The X-mark7 represents the pinnacle of inspection technology, offering unparalleled detection capabilities while maintaining optimal production efficiency. Specially used for PCBA x-ray inspection.
