Large PCB Cooling Buffer

Specification:

Dimension:

PCB Cooling Buffer – Efficient Cooling & Buffering for SMT Lines

The PCB Cooling Buffer is a vital part of the SMT production process, designed to cool down PCBs after reflow soldering while temporarily storing them to ensure smooth workflow between machines. It helps stabilize the board temperature before further handling, inspection, or packaging, preventing thermal shock and ensuring the integrity of solder joints.

This machine combines cooling fans and buffering capability, allowing it to hold multiple PCBs during peak production times. It’s commonly used after the reflow oven, where boards are still hot and require controlled cooling before proceeding to the next step in the line.

Fully compatible with SMEMA standards, the PCB cooling buffer can be easily integrated with other SMT equipment. With an automated indexing system, it ensures smooth, hands-free operation and supports both inline and offline use.

Key Applications:

• Post-Reflow Cooling: Cools hot PCBs before AOI, handling, or testing.

• Production Line Buffering: Temporarily stores boards to manage line flow and reduce bottlenecks.

• Inline Automation: Maintains continuous operation during pauses or slowdowns downstream.

• Solder Joint Protection: Prevents mechanical stress on freshly soldered components by ensuring gradual temperature reduction.

Usage Benefits of PCB cooling buffer:

• Ensures safe cooling of PCBs before further processing

• Balances SMT line speed and prevents machine jams

• Reduces manual handling and risk of thermal damage

• Supports continuous and efficient SMT production

Whether you’re assembling high-density boards or running a high-speed SMT line, the PCB Cooling Buffer is essential for ensuring product quality and improving line efficiency.
