Operating System

• windows operation interface , support windows7.
• Freely switch betweenChinese and English simplifed.
• simple operation.
• perfect function of temperature profile analysis.
• storage and calls.
• operator password , operating log.
• operating parameter digital dynamic display.

2.Schematic Diagram & Feature

• High heat energy, low energy consumption, high power motor matching wind wheel,theoretical and practical verification; under the same conditions set, can ensure the small and large components to achieve the minimum heat absorption difference,and achieve the best thermal balance.

• The latest thermal insulation technology and the new furnace structure design caneffectively reduce the furnace surface temperature and reduce the heat loss.

• Imported PLC program controller, stable and reliable performance,high precision of temperature control and curve repetition

• Double-sided guide rail with special hardening treatment,strong and durable,repeatable use, cost saving up to 50%

• Online maintenance of rosin recycling system, modular design,convenient maintenance, reduce maintenance time

• Patented hot air system, hot air convection conduction more efficient, faster heat compensation

• Built-in real-time monitoring system of furnace temperature,which can automatically generate furnace temperature curve (option)
• Intelligent data can be traced and uploaded to MES system.

3.Technical Details

1. the customer to install control valve to control the import and export of the exhaust volume up to 145.
2. each up to 145 entrance hole exhaust volume control in 15-20M³/min.
3. the main power supply: 3 380V diameter AC five wire, the main power line diameter of more than 35mm².

• Heating Module

Heating module design is easy for maintenance and cleaning  Front and rear re-flow design could insulate the heating effect between heating zones in order to achieve the accuracy temperature and longer life-time of hot-air-flow motors. AIso by the frequent control motors, the speed of air flow could be adjusted.

• Electric Structure

Manual + electric width adjustment structure design,equipped with emergency manual transmission structure in case of preventing PCB burned when power off.

• Transmission

Special adjustable width and transmission design can ensure stable and reliable PCB transmission by anti-Jammed chain High stability control system, powerful function.

 4.Equipment Part Details
